Aug 272017


Every so often, somebody (or organisation) proclaims that this year is the year of Linux on the desktop. Given the number of times this has occurred, you would have thought that the Cassandras of the Linux world would stop trying to predict it. In fact I am not entirely sure what it is supposed to be – everyone using Linux on the desktop, or just some? And if it is just some people, how many?

It is essentially nonsense – if you use Linux on the desktop, every year is the year of Linux on the desktop; and if you do not, it isn’t.

Assuming you are someone who has more than two brain cells to rub together and are prepared to do some learning, it is perfectly possible to run Linux on the desktop. You can do pretty much everything with Linux that you can do with Windows. In fact the one area that Linux is traditionally weak – upgrading firmware of third party devices (such as media players, wireless mice – is beginning to change with LVMS and fwupd.

To give an example, I was recently upgrading some Logitech wireless mice to eliminate a serious security flaw, and I tried with Windows, OSX, and finally Linux. Both the Windows and OSX methods failed, whereas the Linux method just worked.

In fact even if the Windows method had worked, it would have been a lot more complex. I had to download the Logitech software (admittedly this step would probably be unnecessary if I was used to using the wireless mouse under Windows), know that a firmware upgrade was necessary, download the firmware upgrade, and finally load it into the upgrade tool.

Under Linux? Assuming I had been using some gooey tool like GNOME Software, it would have notified me that an upgrade was available and after a request would have upgraded it for me. I (of course) chose to do it the geeky way from the command-line, but even so running :-

# fwupmgr refresh
# fwupmgr update

… is a great deal simpler than the Windows way. And that is before you consider that with Windows, you need to download a firmware update tool for every device whereas the Linux way it is just one tool.

Of course in practice, the Linux method only works for a handful of devices – of the innumerable Linux machines I run only one has available updates for the desktop computer’s firmware (the Dell at work), and of the peripheral (or not so peripheral) devices only a tiny handful can be upgraded today.

But it is not inconceivable that in the not too distant future, the sensible way to upgrade the firmware of various devices will be to install Linux, and let it do it for you. Particularly if device manufacturers realise that by adopting Linux as the firmware upgrade delivery method, they can save time and effort.

“But I know Windows” – actually you know Windows 7, or Windows XP, or Windows 10; each of which is very different from each other. And whilst Linux has even more variability at first glance, there is actually more commonality between different versions of Linux. Or in other words, the effort of learning Linux in the first place is rewarded by less of a need to completely re-educate yourself every time you upgrade.

This is not intended as encouragement for you to switch to Linux (although if you are involved in IT you should at least be familiar with Linux), but intended as a criticism of the concept of a year of the Linux desktop. It isn’t useful, and what is worse it leads to the false impression of failure – if everyone is not using Linux on the desktop, then Linux has failed.

Linux on the desktop has not failed because I use it on the desktop.

Mar 182017


The TiPro programmable keyboards are quite fun for those who are into their keyboards, but with one big problem: the programming tool is Windows only. Well at least if you happen to have a USB-based TiPro; otherwise you need to set up the serial interface as the PS/2 interface is only usable for programming with a 32-bit Windows.

As it turns out, if you try to run it under a virtual machine and assign the USB device of the keyboard to the virtual machine, it still fails – somehow it doesn’t like staying assigned to the virtual machine. However there is a fix for this – using the command-line VirtualBox tools to set up a permanent USB filter.

To assign, first of all determine the name of your virtual machine with :-

VboxManage list vms

Next, add a USB filter – you can normally assign it to “slot” (or index) 1, but you may have to check what slots are available if you already do this :-

VBoxManage usbfilter add 1 --target "W10" --name TiPro --vendorid 0x1222 --productid 0xfaca

Once that is done, the Windows tool should be able to find the keyboard to start programming it. If necessary, reboot the virtual machine or try assigning the USB device via the menu option.

During programming it is helpful to remember than raw USB HID codes can be used by right-clicking in the input field for a key, selecting “Text Input” and inputing the code in the form “/${hex hid code} ${hex hid code}\” – such as “/69 69\” (a list can be found at: http://www.usb.org/developers/hidpage/Hut1_12v2.pdf)

Removal at the end:

VBoxManage usbfilter remove 1 --target "W10"

After the removal it seems that disconnecting and reconnecting the device is necessary for Linux to pick it up (or possibly a udevadm trigger).

b

Sep 012016


One of the advantages that ZFS brings, is that it is so easy to create file systems, that you can create them for purposes that you would not previously do. For example, I have an additional file system mounted under my home directory for a certain application that generates a lot of data that I do not need backed up. Because the script I use to back up stuff does not cross file system boundaries (i.e. it does not descend into a directory that contains a mounted file system), I can simply exclude a large amount of frequently changing data by making a file system.

Or I might (as it happens I do not, but I could well do) create file systems for large lumps of data to easily see how much space they occupy – perhaps ~/Pictures. You can run a command like du -sh ~/Pictures, but that is an expensive command (it takes a while) and it tells you how large the files are; not how much space they occupy on disk. And on-disk compression can make that a significant difference! So simply run df -h ~/Pictures if that directory is on a separate file system.

But there is a bit of a gotcha with that. If you create such file systems in the normal way (such as zfs create pool/mikes-pictures; zfs set mountpoint=/home/mike/Pictures pool/mikes-pictures) you risk creating a situation that may prevent your home directory from mounting. If the “child” file system is mounted before the parent, it will not be possible for the parent file system to be mounted when booting.

Instead create the hierarchy properly :-

zfs create pool/h2
mkdir /h2
zfs set mountpoint=/h2 pool/h2
zfs create pool/h2/mike
zfs create pool/h2/mike/Pictures
ls /h2/mike/Pictures

You will also have to fix the permissions, but this is a far safer way of organising things suitable for future file system creation.

damascus-unix-prompt

Aug 292016


It seems that occasionally GNOME can go a little screwy and its fancy mouse pointer plugin can result in an invisible mouse pointer. Which makes doing anything just a little bit tricky.

If you can open a terminal, enter the command :-

gsettings set org.gnome.settings-daemon.plugins.cursor active false

And all should be well. At least until it decides to turn itself back on again (so make a note of this fix!).

damascus-unix-prompt

Dec 102015


damascus-unix-prompt

You have a a column of numbers that you have produced in some manner such as :-

$ awk '/clean message/ {print $(NF-1)}' mail.info.log
...
100935
12197
3606
84653
4498
99110
4762
3001
10889
12611
12249
12245
136599
49097
6668

And you want a quick and dirty way of finding the largest number. Well there is a way but it is perhaps the least efficient way to do it, and that is to sort the numbers into numerical order and use “head” to display the first one :-

$ awk '/clean message/ {print $(NF-1)}' mail.info.log | sort -rn | head -1
5476168

But frankly there must be a better method. And yes there is if you happen to be using zsh (or possibly others, but this has been tested with zsh). Simply iterate over the values assigning the current value to the “max” variable if the current variable is larger :-

$ max=0; for x in $(awk '/clean message/ {print $(NF-1)}' mail.info.log); [[ $x -gt $max ]] && max=$x; echo $max
5476168

You may be wondering why I don’t simply use the ability of awk to perform calculations. Well that is certainly possible, but I may not always be using awk to produce the numbers in the first place, and this is supposed to be a generic recipe.

Oct 232015


Have you ever wondered if you can tinker with the ps command to change how and what is displayed? No? Well give up reading this post then.

I've known about ps for ages and also the way that the output can be tinkered with, but have not had an excuse to dig into it properly until I was looking for a way for ps to show the Linux container name for each process (don't get excited: ps -o machine is documented but not implemented at the time of writing).

If you read the manual page for ps you will be quickly distracted by all the different options available. These can be grossly simplified into three different groups of options: which processes to list, what to output, and how to sort the output.

Which Processes?

This can be simplified down to almost nothing; ps on it's own lists just the processes running from the current terminal (window) :-

% ps
  PID TTY          TIME CMD
 2591 pts/17   00:00:00 zsh
13325 pts/17   00:00:00 ps

If you want to display all processes, add the "-e" option :-

% ps -e
  PID TTY          TIME CMD
    1 ?        00:00:03 systemd
    2 ?        00:00:00 kthreadd
    3 ?        00:00:00 ksoftirqd/0
    5 ?        00:00:00 kworker/0:0H
    7 ?        00:00:54 rcu_sched
    8 ?        00:00:00 rcu_bh
    9 ?        00:00:35 rcuos/0
   10 ?        00:00:00 rcuob/0
   11 ?        00:00:00 migration/0
   12 ?        00:00:00 watchdog/0
(cut)

And lastly (not literally – there are other options), add the "-p" option to list processes by process ID :-

% ps -p 1
  PID TTY          TIME CMD
    1 ?        00:00:03 systemd

Tuning The Output

By default the fields that ps outputs is somewhat peculiar until you realise that the output fields have been frozen in time. The default choice is somewhat minimal; and I'm not in favour of minimalism. And what use is the TTY and the TIME fields?

The TTY field shows you what terminal the process is running on – this was handy on a multi-user system where you could find out who was on what terminal and then write a message directly to their screen. A great way of winding people up, but not so much use these days. And TIME? We're no longer billed for the cpu time we consume, so the time spent running on the cpu is a rather pointless thing to list.

The "-f" option displays more information :-

% ps -f
UID        PID  PPID  C STIME TTY          TIME CMD
mike     26486 31092  0 21:24 pts/24   00:00:00 ps -f
mike     31092 31091  0 20:11 pts/24   00:00:00 -zsh

But the output is still somewhat peculiar, and there are other more interesting fields to display.

There are various options for choosing the output format amongst a set of predefined choices, but the best bet is to ignore these and jump straight into selecting the individual fields that you want. These can be found in the manual page in the "STANDARD FORMAT SPECIFIERS" section. Simply list the fields you want after the "-o" option :-

% ps -o pid,comm,pcpu,pmem,nlwp,user,stat,sgi_p,wchan,class,pri,nice,flags
  PID COMMAND         %CPU %MEM NLWP USER     STAT P WCHAN  CLS PRI  NI F
28061 ps               0.0  0.0    1 mike     R+   3 -      TS   19   0 0
31092 zsh              0.0  0.0    1 mike     Ss   * -      TS   19   0 0

Obviously typing this in every time is somewhat less than ideal, but fortunately the authors of ps have already thought of this. By listing the fields within the PS_FORMAT environment variable, there is no need to specify -o :-

% export PS_FORMAT="pid,comm,pcpu,pmem,nlwp,user,stat,sgi_p,wchan,class,pri,nice,flags"
% ps
  PID COMMAND         %CPU %MEM NLWP USER     STAT P WCHAN  CLS PRI  NI F
29440 ps               0.0  0.0    1 mike     R+   5 -      TS   19   0 0
31092 zsh              0.0  0.0    1 mike     Ss   * -      TS   19   0 0

To make this pernament, add this to your shell startup rc file; whilst editing you may as well set PS_PERSONALITY to "linux".

Sorting The Output

According to the ps documentation, by default the output is not sorted. In that case either my kernel's process table is remarkably well organised, or the distributions I use "cheat" and sort the output in process ID order. In the distant past where computers were shared amongst too many people, and the machines themselves were quite slow, it made sense for the output of ps to be unsorted. But it certainly doesn't make sense now.

And the ps command allows processes to be sorted by any field that you can specify in the "STANDARD FORMAT SPECIFIERS" section which conveniently enough you are now intimately acquianted. Simply add the relevant field to the –sort option :-

% ps --sort pcpu
  PID COMMAND         %CPU %MEM NLWP USER     STAT P WCHAN  CLS PRI  NI F
31092 zsh              0.0  0.0    1 mike     Ss   * -      TS   19   0 0
31743 ps               0.0  0.0    1 mike     R+   5 -      TS   19   0 0

With just a short list (and such a low percentage of the cpu in use) it doesn't make sense, but added to -e, it does.

Rather than change the default sort order, I personally prefer to configure aliases to do the job for me :-

% alias pscpu='ps --sort pcpu'
% alias psmem='ps --sort pmem'

Preferring to use an alias here is rather convenient as there doesn't seem to be a way to configure the default sort order – officially there isn't one!

Reading through the ps manual page (during which you will notice many different options referring to old Unix varients) is a reminder of just how long and bitter the fight over which ps varient was the best. And now for a completely irrelevant picture :-

damascus-unix-prompt

Mar 072015


So there I was, wandering down the street thinking about :-

  1. Sometimes being unable to remember custom key sequences that I've configured.
  2. That my "Help" button on my keyboard was unused.

And I thought that it would be fun to knock up a little application that would pop up a window and show a file. Then I got real, and realised that the application was already written and allowed fancy formatting of the help file(s) – it's called a browser.

Now for a whole bunch of reasons, you probably don't want to use a full blown browser, but something a little simpler and without any fancy controls, and I plumped for dilloTurns out that the "-f" flag turns off the fancy menu and toolbar, so what I needed was to persuade my window manager (Awesome) to run it when I pressed "Help" :-

	awful.key({ }, "Help", function () awful.util.spawn("dillo -f /home/mike/lib/help-files/index.html") end))

If you need help adding that to your Awesome configuration file, you're in the wrong place!

And of course it works :-

2015-03-07_1457

(And now of course I need to spend some time writing some help files!)

Feb 022015


Undocumented command options … grrr!

Every so often I find that I have a need to put a volume label onto a FAT filesystem – usually so a digital camera SD (or CF) card can be "automatically" mounted (actually they don't mount automatically on my workstation and I like it like that) in the right place. And of course every time I do, I remember that the command to do so is mlabel but I cannot remember exactly how to do it.

Because mlabel (together with the other mtools) has some sort of weird configuration file to turn Unix/Linux paths into drive letters‽ And yes that was an interribang although it could just as well be some other form of punctuation to express disgust instead. As it happens mlabel has an undocumented option to specify a device path … at least it doesn't appear in the usage hints :-

» mlabel -h
Mtools version 4.0.17, dated June 29th, 2011
Usage: mlabel [-vscVn] [-N serial] drive:

It turns out that there is a "-i" option which takes a device path, but you still have to specify the drive as "::" just so things are less likely to go right :-

» mlabel -i /dev/sdi1 ::
 Volume has no label
Enter the new volume label : LEICA1

And there it is!

Aug 152014


This post is likely to change frequently after it first appears as experiments/research/etc. occurs to me.

To get to grips with it, let’s first define the software that is in control of your PC when it first starts as the system firmware rather than the BIOS, as system firmware is a generic term which can refer to BIOS, EFI, UEFI, OpenFirmware, or anything else that someone comes up with.

UEFI (and the older EFI) is a replacement for the legacy BIOS that we’ve been stuck with for decades. Despite advances in almost every aspect of the “PC standard”, the BIOS has hardly advanced at all. To be fair, the user interface has gotten a bit less 1980s, and it of course deals with hardware devices that weren’t even imagined decades ago. But there are still some rather nasty limitations, which UEFI is supposed to resolve.

Of course there are those who claim that UEFI is a complete mess with no redeeming qualities, but the truth is probably somewhere between it being that and the neatest bit of system firmware ever invented.

This posting are my working notes (with the addition of a bit of pointless waffling) on UEFI, given that I’m likely to be found staring at a UEFI shell on a broken server at some point in the future. All experiments (so far) have been carried out with a VirtualBox-powered virtual machine (with UEFI turned on) running Ubuntu server.

Installation

The boot process looks a little different … unsurprisingly. And there’s an error in relation to missing UEFI stuff from the hard disk. But once the CD is booted the process looks the same …

Partitioning: Initially “Guided – use entire disk and set up LVM”

Doesn’t give an opportunity to review the partitioning, but :-

  1. EFISystem (/boot/efi) is roughly 512Mbytes
  2. /boot is roughly 256Mbytes
  3. LVM Volume Group

The Ubuntu installation uses grub as the boot loader, although it’s hardly the only option and there are hints that grub has been known to have issues with EFI. Although this could be “early adopters pain”, and not applicable currently.

GPT Partitions

See the Wikipedia article, but basically GPT replaced the old Master Boot Record partitions. The main advantage is that there are fewer dumb limits with GPT – there is no limit of 4 primary partitions (and no hacks to support extended partitions), but instead a minimum maximum of 128 partitions, which basically translates as the required minimum size of a partition table allows for up to 128 partitions but the partition table can be bigger.  More than you’re likely to need anyway.

Cleverly (if you want to put it that way), GPT can live alongside the old MBR partitions as the GPT starts at block 1 rather than block 0. This has been used by Apple to keep two partition tables so that OSX can use GPT whilst Windows still uses MBR.

Keeping two partition tables in sync is perhaps not the best idea for stability and given the need for backwards compatibility has only a limited useful lifetime, I’d rather live without it. In fact it would be nice if I could fill up the old MBR with stuff that told all MBR tools not to mess around with the partition tables.

In theory, (U)EFI and GPT are independent of each other, but in practice, GPT implies booting from UEFI and MBR implies booting from BIOS (some UEFI implementation switch to a BIOS-compatibility mode when they see an MBR).

The EFI System Partition

(U)EFI requires that to boot, a disk must have an EFI System Partition formatted as FAT. This is used as effectively a replacement for the BIOS boot method of loading code from block 0. This file system is usually mounted under Linux as /boot/efi and contains various files that allow Linux to be booted (more details to be added).

It is perhaps a shame that the EFI standards people didn’t suggest making the EFI system partition part of the on-board firmware. It wouldn’t be impossible (or very expensive) to incorporate a small writeable FAT file system into the motherboard to avoid the need for the EFI partition on one of the storage disks. It is not as if the EFI system partition needs to be very big – Ubuntu configured one as 512Mbytes in size which is vastly larger than required for what is actually installed which adds up to less than 4Mbytes.

EFIBOOTMGR

The tool efibootmgr is for interacting with the EFI boot manager and the EFI variables that control what gets booted in which order :-

# efibootmgr
BootCurrent: 0003
BootOrder: 0003,0000,0001,0002
Boot0000* EFI DVD/CDROM
Boot0001* EFI Hard Drive
Boot0002* EFI Internal Shell
Boot0003* ubuntu

The command has plenty of other options …

You can set the boot order with: efibootmgr -o 0002,0003,0001,0000. So I’ve set the preferred boot order to include the internal shell first … the purpose here is to look into EFI after all.

I also somehow managed to erase the “ubuntu” so re-created that with: efibootmgr -c -L UbuntuServer -l “\EFI\ubuntu\shimx64.efi” (yes unfortunately they use the wrong path separator).

EFI Shell

Is surprisingly limited. And rather too DOS-like for me.

Command Description
help Displays a list of the commands available … which very unhelpfully doesn’t pause at the end of the screen. Can also display additional details of a command if you try help command.
mode Displays a list of the available screen mode commands.
mode x y Sets the screen mode to the size specified (as listed with mode).
cls Clears the screen.
cls ${n} Clears the screen and sets the colours to a set specified by the number (0-7). Don’t bother; most of the choices are nasty.
map Displays teh mapping table showing the block devices (BLK${n}) and the recognised file systems (FS${n}). If you don’t have fs0 you’ve got problems!
fs0: Sets the specified file system as the current file system. This will change the prompt appropriately.
cd ${directory} Changes to the specified directory. Remember that the path separator is the DOS preferred character (\).
ls Lists files in the current directory.
edit ${filename} Edits the specified file (^S saves, ^Q quits), but don’t try editing files ending in .efi!
${filename}.efi Runs the EFI binary from the current directory, and yes that does mean you can boot Ubuntu Server by browsing to the \EFI\ubuntu directory and entering shimx64.efi (as I discovered after breaking the ubuntu boot option).
Aug 022014


One of the questions I always ask myself when setting up a resilient server, is just how well will it cope with a disk failure? Ultimately you cannot answer that without trying it out.

But as practice (and to determine whether it mostly works), it’s perfectly sensible to try it out on a virtual machine.

Debian Installation

If you are looking for full instructions on installing Debian, this is not the place to look. I configured the virtual machine with 2GBytes of memory, an LsiLogic SAS controller with two attached disks each of 64GBytes.

The installation process was much as per normal (I unselected “Desktop” to save time), but the storage was somewhat different :-

  • Manual partitioning method
  • Create an empty partition on both disks
  • Select Software RAID
  • Create an MD device
  • RAID1
  • And put both disks into the RAID
  • Configure LVM
  • Create a Volume Group (“sys”)
  • Select md0 for the volume group device
  • Create logical volumes (boot: 512MB, root: 16GB, var: 8GB, home: 512M (it’s a server))
  • In the partitioning manager select each Logical Volume in turn and specify the file system parameters.

You will notice that no swap was created – this was a mistake that I’m in the unfortunate habit of making! However for a test, it wasn’t a problem and with LVM it is possible to create swap after the installation.

Post Installation

After the server has booted, it is possible to check the second hard disk for the presence of grub in the MBR (dd if=/dev/sdb of=/var/tmp/sdb.boot bs=1M count=1, and then run strings on the result). It turns out that nothing is installed in the MBR of the second disk by default. Which would make booting in a degraded environment an interesting challenge (i.e. you’ll have to find a rescue CD and boot off the relevant hard disk).

However this can be fixed by installing grub onto the second hard disk: grub-install /dev/sdb

Testing Resilience

But what happens when you lose a disk? Now is the time to test. Shut down the virtual machine and remove the second hard disk – leaving the first hard disk in place does not provide a full test.

If your first attempt at booting afterwards results in a failure to acquire a grub menu, then either you have failed to run grub-install as detailed above (guess what mistake I made?), or your BIOS settings don’t permit the computer to boot off anything other than the first hard disk.

However, in my second attempt, the server booted normally with the addition of a few messages that indicate that there is just one disk making up the mirrored pair.

Summary

  1. Yes, you can put /boot onto an LVM file system that sits on mirrored disks. That hasn’t always been the case.
  2. It is still necessary to run grub-install to put Grub onto the MBR of the second hard disk.
  3. It works.
